CCTV Power Supply 30amps (closed)
CCTV cameras – Power supply for 32 channel
DC VOLTS – 12V
total output – 30 Amp
Input – AC 110 V-240 V
category – CCTV cameras
KSh 5,500.00
CCTV 30A Power supply:
Get the DC 12V 30AMP – Fused With Casing – CCTV Distributed Power Supply Box For Security Camera from our stores
A CCTV power supply box, also known as a power distribution box, allows surveillance system installers to easily manage the power to multiple CCTV cameras at a central point (usually at the location of the DVR)
This box is designed to be used when you need to power security cameras that demand higher power inputs. This unit can provide up to 30 amps of 12V DC power which is more than twice the power output of the average power supply.
If you are using long-range infrared cameras that use 12V DC power, we highly recommend this power supply.
This box is a 12V DC output, 30 amp regulated. Each channel individually fused using PTC auto-reset fuses rated at 1.6 amps. This power distribution box can power up to 16 CCTV cameras, HD security cameras, or IP cameras.
The required power input is 110~120VAC. This power supply box can wire using the 18/2 conductor cable from RG59 Siamese as well as pre-made security camera cables.
Powering multiple cameras could not be easier! line of Professional CCTV Power Supplies give installers what they expect when it comes to power supplies quality and reliability
Every channel protected with Auto-Reset PTC fuses which means these fuses will Not blow
This box can mount to any surface plugged into an AC outlet and up in seconds!
12VDC – 30amp supply current | Multiple outputs (32 channel) | 32 auto-reset PTC fuse protected output | Power on/off switch
DC regulated, over current and voltage protected | Individual LED indicator for each out put | Dimensions:25cm21.3cm9.5cm | Fuse Rating: 1.1A
Features for 30a CCTV power supply:
The 12V 30Amps CCTV power supply is made of high-quality aluminum alloy material, rust resistance, and corrosion resistance, solid and durable in use.
There are two cooling methods: free air convection(where the power supply cools with ventilations i.e. holes located on the upper part).
cooling and fan cooling(where the power supply cools with the use of a fan located on the upper part or on the side).
With a short circuit protecting function and over-temperature protecting function, the power supply is safe and reliable to use.
Easy and convenient to install, though professional installation by qualified electricians is highly recommended.
12v 10amps CCTV power supply has a long durability life span, with long withstanding power input for up to 220v and input for up to 110v, this basically helps when using the normal homestead input power.
Widely applicable for LED display lights and signboards, household equipment, industrial equipment, monitoring equipment, industrial automation machinery, industrial control systems, mechanical and electrical equipment, electronic instruments and equipment, etc.
Additional Input
Powering multiple cameras could not be easier! line of Professional CCTV power supplies gives installers what they expect when it comes to power supplies, quality, and reliability.
Every channel protected with Auto-Reset PTC fuses, which means these fuses will not blow. This box can mount to any surface, plugged into an AC outlet, and up in seconds! Video Baluns can easily be added by using DC Power Pigtails.
- Powering multiple cameras could not be easier! line of Professional CCTV power supplies gives installers what they expect when it comes to power supplies quality and reliability.
- Every channel protected with Auto-Reset PTC fuses which means these fuses will not blow.
- This box can mount to any surface plugged into an AC outlet and up in seconds!.
- 12VDC – 30amp supply current. Multiple outputs (16 channels). 16 auto-reset PTC fuse protected output. Power on/off switch
CCTV CAMERA POWER POWER SUPPLY: 12 volt 30amp (DC)
COLOR: SILVER
CONDITION: CCTV CAMERA POWER SUPPLY
VOLT: 12V
DC CAPACITY: 30
Amp It is Capable to Run Maximum 8 Camera.
Description
- High efficiency, long life, and high reliability
- Low dc ripple, high efficiency
- Low operation temperature & long performance life
- Excellent insulation property, high dielectric strength
- 100% full-load burning test
Input:
- Ac input voltage range(v): ac 220v-240v±15% (switch replacement)
- Input current(a): 6.5a /115v,4a /230v
- Frequency (Hz): 50/60hz
- Efficiency: 91% typ(230vac full load)
- Inrush current(a): 25a/115v 50a/230v cold start
- Leakage current(ma): 115%-135% rated output voltage
- Overload protection: >105%-150% auto-recovery
- Short circuit protection: latched
high voltage protection: when high voltage occurs, the surge protection will hit through to protect the connected device
overcurrent protection: when over current occurs, the supply will automatically switch to self-protection status, when condition removed, then switch back to normal
Item Weight | 1 kg |
---|---|
Main Material | Metal |
Brands | Hikvision |
